628DV x-ray scanner

Dual view low conveyor easy loading and unloading

Security_X-ray scanner_Conventionnal X-ray scanner_628DV x-ray scanner

With a 1,000 mm (39.4 inches) wide by 1,000 mm (39.4 inches) high tunnel opening, the Rapiscan 628DV is designed for customers that need to inspect small cargo as well as baggage and large parcels.

Supplier: Rapiscan

Caracteristics

  • Advanced Cargo Screening
  • Facilité de chargement
  • Dual View technology

Rapiscan 628DV (Dual View) provides a horizontal and vertical view of the object under inspection to improve throughput and object discrimination. These two perpendicular views provide a complete perspective of complex parcels regardless of their orientation in the X-ray system. Dual view technology eliminates the need for screeners to reposition and re-scan parcels in high security environments. Like all systems in the 600 series family of X-ray scanning solutions, the Rapiscan 628DV is built on a standardized platform that makes it easy to install and maintain, and comes with features such as dual-energy detection, a streamlined, ergonomic design, and Rapiscan’s feature-rich OS600 system software.

Specifications

  • Dimensions (LxHxW) : 4,360 x 2,200 x 2026 mm
  • Tunnel Size : 1000 mm (W) x 1000 mm (H)
  • Conveyor Speed: 0.20 m/sec
  • Conveyor Max Load: 165 Kg evenly distributed
  • Approx Weight: Net: 1550 Kg

Product applications

  • Large parcel and small cargo screening, easy loading conveyor, dual view
