632XR x-ray scanner

Heavy-duty roller conveyor designed to inspect pallets weighing up to 3000 Kgs

Security_X-ray scanner_Conventionnal X-ray scanner_632XR x-ray scanner

With a 1,000 mm (39.4 inches) wide by 1,000 mm (39.4 inches) high tunnel opening, the Rapiscan 628DV is designed for customers that need to inspect small cargo as well as baggage and large parcels.

Supplier: Rapiscan

Caracteristics

  • Pallets and cargo screening
  • Heavy Duty Roller Bed
  • Network Enabled

Like all systems in the 600 series family of X-ray scanning solutions, the Rapiscan 632XR is built on a standardized platform that makes it easy to install and maintain, and comes with features such as dual-energy detection, a streamlined, ergonomic design, and Rapiscan’s feature-rich OS600 system software.

Specifications

  • Dimensions (LxHxW) : 6,492 x 2,042 x 2874 mm
  • Tunnel Size : 1500 mm (W) x 1650 mm (H)
  • Conveyor Speed: 0.20 m/sec
  • Conveyor Max Load: 3000 Kg evenly distributed
  • Approx Weight: Net: 2154 Kg

Product applications

  • Pallet and cargo screening
