Jaw Crusher PULVERISETTE 1 premium line
Fritsch
The extra powerful premium pre-crusher
The extra powerful FRITSCH Jaw Crusher PULVERISETTE 1 premium line with its up to 3 kW drive power ensures an exceptionally high throughput and is the ideal instrument for fast and effective pre-crushing - batchwise or continuous – of hard or very hard brittle materials even hardest ferrous alloys!
Advantages
- Final fineness 0.3-15 mm
- Zero-point and grinding gap adjustment with millimetre accuracy
- Variable crushing jaw kinematics for higher final fineness
- Easy cleaning: crushing jaws can be completely swivelled out or removed
Description
Specification
Applications
Resources
The powerful comminution of the sample takes place in the Jaw Crusher under high pressure between one fixed and one movable crushing jaw in an enclosed grinding chamber. The gap adjustment is defined with millimetre accuracy from the outside, simply by adjusting the distance between the crushing jaws.
- Dimensions : 55 x 90 x 106 cm
- Working principle : pressure
- Optimal for material type : very hard, hard, medium-hard, brittle and abrasive samples and for metal-free grinding
- Grinding tools : fixed and movable crushing jaws
- Materials of the grinding tools : hardened steel, stainless steel, chromium-free tool steel, manganese steel, hardmetal tungsten carbide, zirconium oxide
- Max. feed size (depending on material) : 95 mm
- Min. sample quantity : 20 ml
- Max. continuous throughput (depends on material and gap width) : 250 kg/h
- Final fineness : 0.3 – 15 mm
- Glass and ceramics industry
- Mining and metallurgy
- Geology and mineralogy
- Chemical industry
- Soil research
Brochure
Jaw Crusher PULVERISETTE 1 premium line (pdf / 701,5 KB)
