Multi-Channel 19020 Dielectrometer
The only dielectrometer that can test more than 100 DUT
The dielectric family 19020 allows you to perform up to 100 dielectric tests (0.05kV - 6kV), DC (0.05kV - 8kV) and insulation resistance (1MΩ - 50GΩ).
Advantages
- Master-slave configuration up to 10 testers
- Dielectric tests AC, DC and IR
- More security: Synchronizable outputs, OSP, duction detection on DUT
- Ramp and Limit Programming
The Guardian 19020 Multi-Channel Electrical Strength Tester allows you to test with 10 instruments simultaneously (DUT) and more than 100 with several instruments in master/ slave configuration. The 19020 tester family includes 5 instruments:
19020: 10-way dielectric tester for AC tests (0.05kV-5kV), DC (0.05kV-6kV) and insulation resistance measurement (1MΩ-50GΩ)
19020-4: 4-way tester for dielectric tests AC (0.05kV-5kV), DC (0.05kV-6kV) and insulation resistance measurements 51MΩ-50GΩ)
1921: 10-way dielectric tester for AC tests (0.05kV-6kV)
19022: 10-way dielectric tester for DC tests (0.05kV-8kV) and insulation resistance (1MΩ-50GΩ)
19022-4: 4-way dielectric tester for DC tests (0.05kV-8kV) and insulation resistance (1MΩ-50GΩ)
- 19022 and 19022-4: DC (0.05kV-8kV) and IR (1MΩ-50GΩ) tests)
- 19020 and 19020-4: AC tests (0.05kV-5kV), DC (0.05kV-6kV) and insulation resistance measurement (1MΩ-50GΩ)
- Voltage / current resolution: 2V, 1μA
- Internal memory
- RS232 and GPIB interface (option)
- Test de cables éléctriques, moteur, adaptateur
- Tests sur batteries
- Tests sur switch, transformateurs,
- Tests normatifs : IEC, UL, TUV, CSA, EN
