Preamplifier Model 5185
The model 5185 is a wideband voltage preamplifier with a frequency response from DC to 200 MHz and switchable gain settings of x10 (20 dB) or x100 (40 dB).
- Very wide band
- Variable gain
- DC offset control
The low-noise preamplifier 5185 is characterized by its very wide range of amplification of the DC to more that 200MHz with gains of 20dB or 40dB. Designed by EG & G, and now manufactured by SIGNAL RECOVERY, it can operate on mains and its input impedance may be 50Ω or 1MΩ. It is specially suited to increase the sensitivity of oscilloscopes or it can be used as a fast ADC converter.
- DC response to 200MHz
- Input impedance 50 Ω or 1 MΩ // 25 pF
- Gain 20dB or 40dB
- Noise 10 nV / √Hz to 10Khz
- Battery or power supply
- ADC rapide
- Augmenter la sensibilité de votre Oscilloscope
- Préamplification pour moyenneur numérique et boxcar
